MXU 400
SIMPLICITY AT ITS BEST.
With the simplicity of a carburettor and the reliability of an air and oil cooled engine, the KYMCO MXU400 is the choice of farmers. Practical power delivered through a CVT automatic transmission with selectable high / low range for flexible work speeds. Independent suspension all round and push button selectable 2WD / 4WD will keep you moving not matter the terrain. Simplicity at it best, KYMCO MXU400.
RELIABLE FOUR-STROKE ENGINE
Air/oil cooled, four stroke engine with 4 valve SOHC
SIMPLICITY OF A CARBURETTOR
Back to basics reliability of a Keihin carburettor
HIGH / LOW RANGE SELECTOR
CVT automatic transmission with high / low range selector
ACTIVE ENGINE BRAKING
Active engine braking retards excess speed
SELECTABLE DRIVE MODES
Push button selectable 2WD / 4WD will master any terrain
EASY ELECTRIC START
Electric start makes starting simple every time
SUPERIOR BRAKING PERFORMANCE
Front and rear linked hydraulic disc brakes provide superior braking performance
PARK BRAKE
Parking brake for safe parking while the rider is off the machine
BROAD HALOGEN LIGHTING
Twin front halogen head lamps with high / low beam provide a broad spread of light
STRONG FRONT AND REAR CARRY RACKS
Front and rear carry racks allow you to haul additional equipment
STRAIGHT FORWARD INSTRUMENTATION
Backlit digital dash with speedometer, clock, trip meter, fuel and temperature indicators
FRONT AND REAR INDEPENDENT SUSPENSION
Dual a-arm front and rear independent suspension provides 10.5 inches of ground clearance
ADJUSTABLE SHOCK ABSORBERS
Adjustable shock absorbers offer 7 inches of travel for stable handling
DURABLE STEEL WHEELS
12 inch steel wheels are durable and simple to keep clean
CONVENIENT 12V DC OUTLET
Sealed 12V DC outlet to charge your devices or run a spot light
LARGE FUEL TANK
Large 15 litre fuel tank will allow you to travel further between filling up
INCREASED TYRE SIZE
Large 24×8-12 inch front and 24×10-12 inch rear tyres deliver unbeatable traction
UNDER SIDE SKID PLATES
Front brush guard and under side skid plates deflect debris from vital components
DEEP UNDER SEAT STORAGE
Secure under seat storage provides additional storage capacity
FACTORY WARRANTY
Three year warranty program* supported by a national dealer network
Engine
Engine | SOHC, air & liquid-cooled, four-stroke |
---|---|
Displacement | 367cc |
Power20 | 20 HP @ 6500 RPM |
Bore x Stroke | 81 x 71.2 mm |
Compression ratio | 9.2:1 |
Fuel system | Carburetor |
Ignition | ECU |
Starting system | Electric |
Transmission | CVT automatic with dual range and reverse gear |
Final drive | Push button selectable 4WD, Shaft |
Suspension
Front suspension | Independent dual a-arm with twin shock absorbers |
---|---|
Rear suspension | Independent dual a-arm with twin shock absorbers |
Front tire size | 24 x 8 – 12 inch |
Rear tire size | 24 x 10 – 12 inch |
Front brakes | Hydraulic disc |
Rear brakes | Hydraulic disc |
Capacity | |
Carrying | 34 kg (front) / 68 kg (rear) |
Towing | 447 kg |
Size / Weight
Length x Width x Height | 2123 mm x 1102 mm x 1192 mm |
---|---|
Wheelbase | 1217 mm |
Seat height | 843 mm |
Ground clearance | 268 mm |
Fuel capacity | 15 l |
Dry weight | 276 kg |
Other | |
Colour choices | Red |
Warranty | 3 year factory program* |
*KYMCO products are supported by our 3-year factory warranty program. The program provides warranty for a period of two years from the date of purchase. However, if you have your vehicle serviced exclusively at an authorised dealer and retain an accurate service history, you may be eligible for a further one year extension. For more details, contact your local KYMCO dealer.
